| Specifications | ||
| Physical / Electrical / Environmental | Dimensions (No Mount) | 362 x 267 x 184 mm (14.25 x 10.51 x 7.24") |
| Weight (No Mount) | 750 g (24.11 oz) | |
| Mounting Kit | Pole Mounting Kit (Included) | |
| Max. Power Consumption | 4W | |
| Power Supply | 24V, 0.2A PoE Adapter (Included) | |
| Power Method | Passive PoE (Pairs 4, 5+; 7, 8 Return) | |
| Operating Temperature | -40 to 70° C (-40 to 158° F) | |
| Operating Humidity | 5 to 95% Noncondensing | |
| Shock and Vibration | ETSI300-019-1.4 | |
| ETSI Specification | EN 302 326 DN2 | |
| ESD/EMP Protection | ± 24 KV Contact / Air | |
| System Information | Processor Specs | Atheros MIPS 74Kc, 533 MHz |
| Memory | 64 MB | |
| Networking Interface | (1) 10/100 Ethernet Port | |
| Antenna Information | Operating Frequency | Worldwide: 5150 - 5875 MHz |
| USA: 5725 - 5850 MHz | ||
| Output Power | 25 dBm | |
| Gain | 23 dBi | |
| Max. VSWR | 1.5:1 | |
| Regulatory / Compliance Information | Wireless Approvals | FCC, IC, CE |
| RoHS Compliance | Yes | |
