The WP822 is a portable Wi-Fi IP phone designed to suit a variety of enterprises and vertical market applications, including retail, logistics, medical and security. This business-grade Wi-Fi phone comes equipped with integrated dual-band 802.11a/b/g/n/ac Wi-Fi, an advanced antenna design and roaming support. By adding 8-hour talk time, HD voice with dual-MICs, and a configurable push-to-talk button, the WP822 comes equipped with a combination of features, mobility and durability to suit all portable telephony needs.



• Dual-band Wi-Fi with efficient antenna design and advanced roaming support
• 2 SIP accounts, 2 lines
• HD voice & dual MIC design with AEC and Noise Shield Technology
• Rechargeable 2000mAh battery, 8 hour talk time, 200-hour standby
• Integrated Bluetooth to connect headsets
• Configurable button for push-to-talk
• Micro USB port and 3.5mm headset jack





  Specifications
  Protocol/Standards	SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, SSH, TFTP, NTP, STUN, SIMPLE, 802.1x, TLS, SRTP, IPv6
  Voice Codecs and Capabilities	Support for G.711µ/a, G.729A/B, G.722 (wide-band), iLBC, Opus, in-band and out-ofband DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC, ANS
  Wi-Fi	Yes, integrated dual-band Wi-Fi 802.11 a/b/g/n/ac (2.4GHz & 5GHz). 802.11k/r/v Supported (WPA2/WPA2-Enterprise).
  Wi-Fi Encryption	WEP, WPA/WPA2, WPA Enterprise, WPA3, WPA3-Enterprise
  Graphic	2.4 inch (240x320) TFT color LCD
  Bluetooth	Yes, integrated
  Peripherals	3 soft keys, dial, hang-up, speakerphone, phonebook, backlit keypad, proximity sensor, vibration motor, volume button, navigation keys, and accelerometer supporting configurable gestures
  Push-to-Talk	Customizable button for push-to-talk
  Auxiliary Ports	3.5 mm headset jack, Micro USB port for charging, dual-MIC, dual-color MWI LED
  Telephony	Hold, transfer, forward, 3-way audio conference, call waiting, call log (up to 100 records), downloadable phonebook (XML, up to 500 items) off-hook auto dial, auto answer, flexible dial plan, personalized music ringtones, server redundancy and fail-over, push to talk, LDAP
  Security	User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES based secure configuration file, SRTP, TLS, 802.1x media access control
  HD Audio	Yes, both on handset and speakerphone with support for wideband audio, HAC supported
  QoS	802.11e (WMM) and Layer 3 (ToS, DiffServ, MPLS) QoS
  Multi-language	English, Chinese, German, French, Italian, Portuguese, Russian, Spanish, and more
  Upgrade/Provisioning	Firmware upgrade via TFTP/HTTP/HTTPS/FTP/FTPS, mass provisioning using encrypted XML configuration file, manual upload
  Power & Green Energy Efficiency	Universal power adapter included Input: 100-240VAC Output: +5VDC, 1A (5W) 2000mA Li-ion battery, 200h standby time and 8h talk time
  Physical	Handset dimensions: 164.0 x 52.0 x 25.8mm Charger cradle dimensions: 77.9 x 81.2 x 38.2mm Handset weight: 185.90g Handset package weight (not including QIG): 422.60g
  Temperature and Humidity	Operating Temperature: 0ºC to 45ºC Operating Humidity: 10-90% (non-condensing) Storage Temperature: -20ºC to 60ºC Storage Humidity: 10-90% (non-condensing)
  Package Contents	Handset unit, universal power supply, charger cradle, belt clip, 1 Li-ion battery, Quick Start Guide
  Compliance	FCC, CE, RCM, IC, UKCA
