8-Port Gigabit PoE+ Switch (120W
171.12€
228.16€
Description
- 8 x Gigabit PoE+ ports
- 65W PoE power budget
- 16Gbps switching capacity
- IEEE 802.1p QoS and DSCP pass-through support
- Compact fanless design
- Wall-mountable metal housing
| Specifications | |
| Standards | IEEE 802.3 |
| IEEE 802.3u | |
| IEEE 802.3ab | |
| IEEE 802.3x | |
| IEEE 802.3p | |
| IEEE 802.3af | |
| IEEE 802.3at | |
| Device Interface | 8 x Gigabit PoE+ ports |
| LED indicators | |
| Data Transfer Rate | Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) |
| Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) | |
| Gigabit Ethernet: 2000Mbps (full duplex) | |
| Performance | Switch Fabric: 16Gbps |
| RAM Buffer: 192KB | |
| MAC Address Table: 4K entries | |
| Jumbo Frames: 9KB | |
| Forwarding rate: 11.9Mpps (64-byte packet size) | |
| Special Features | 802.1p Class of Service (CoS) |
| Wall mountable | |
| Power | Input: 100 – 240 V AC, 50/60Hz, 2.5A |
| Output: 55V DC, 1.3A external power adapter | |
| Max. consumption: 71W | |
| PoE | PoE budget: 65W |
| PoE Mode A: Pins 1,2 for power and pins 3,6 for power | |
| Operating Temperature | 0° – 40° C (32° – 104° F) |
| Operating Humidity | Max. 90% non-condensing |
| Dimensions | 240 x 105 x 27mm (9.45 x 4.13 x 1.1 in.) |
| Weight | 580g (20.45 oz.) |
| Certifications | CE |
| FCC | |
| LVD | |
