16-Port Gigabit Desktop Switch

141.36€
188.48€
TEG-S17D

Description

The 16-Port Gigabit Desktop Switch, model TEG-S17D, provides high bandwidth performance, ease of use, and reliability. Boost office network efficiency and eliminate network congestion with gigabit speeds and a total switching capacity of 32Gbps with full-duplex mode. A built-in universal power supply reduces cable clutter, and diagnostic LEDs help with network troubleshooting. Plug and play this sturdy metal switch for reliable high-speed network connectivity.





Features

  • 16 x Gigabit RJ-45 ports
  • Sturdy metal desktop switch
  • Built-in power supply
  • 32Gbps forwarding capacity
  • Fanless design
  • 1U rackmount brackets included
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty*
Specifications
Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
Device Interface
  • 16x Gigabit ports
  • LED indicators
Data Transfer Rate
  • Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
  • Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
  • Gigabit: 2000Mbps (full duplex)
Performance
  • Switching Capacity: 32Gbps
  • RAM Buffer: 512KB
  • MAC Address Table: 8K entries
  • Forwarding Rate: 23.8Mpps (64-byte packet size)
  • Jumbo Frames: 9KB
Special Features
  • Rack Mountable
Power
  • Internal power supply: 100 – 240V AC, 50/60 Hz, 0.2A
  • Max. Consumption: 9.19W
Fan/Acoustics
  • Fanless design
MTBF
  • 1,1121,721 hours
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions (L x W x H)
  • 216 x 132 x 43mm (8.5 x 5.20 x 1.69 in.)
Weight
  • 414g (14.6 oz.)
Certifications
  • FCC
  • CE
  • ETL
Warranty
