DS-3E0109P-E (C) 8-Port 100 Mbps Long-Range Unmanaged PoE Switch Hikvision
Future & Function
Intelligent PoE Management.
• When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
Up to 300 m Long Range PoE Transmission.
• The distance between IPCs and switch can reach maximum 300 meters. 4/8-Core Adaptive Power Supply with Less Power Loss.
• 8-core power supply reduces the power loss on cables. 6KV Surge Protection to Improve Reliability in Harsh
Environment
• The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
Design for Video Transmission.
• VIP port ensures important data transmission when network congestion occurs.
| PoE Ports 10/100M RJ45 | 8 |
| PoE port | 1 - 8 |
| Port of high priority | Ports 1 - 2 |
| Switching Capacity | 1.8 Gbps |
| Switch max. power | 240W |
| PoE Standard | IEEE 802.3af, IEEE802.3at |
| Port max. power | 30W |
| Power Supply | 48 VDC, 2.5 A |
| Power Consumption | 5W |
| Working Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity | 5% to 95% (no condensation) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Storage Humidity | 5% to 95% (no condensation) |
| Weight | 0.35 kg (0.77 lb) |
