| Sensor |
1/2.8" Progressive Scan CMOS |
| Max. Image Resolution |
1920 x 1080 |
| Minimum Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR on |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Lens |
2.8mm |
| Adjustment Range |
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Day& Night |
ICR Cut |
| Wide Dynamic Range |
120 dB |
| Digital Noise Reduction |
3D DNR |
| Video Compression |
Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| Video bit Rate |
32 Kbps to 8 Mbps |
| Ingress Protection IP |
IP67 |
| WDR |
120dB |
| Network Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE |
| Local Storage |
SD Card |
| Working Temperature |
-30 °C to 60 °C (-22 °F to 140 °F). |
| Power Consumption |
12 VDC, 0.4 A, max. 5 W PoE (802.3af, 36 V to 57 V), 0.2 A to 0.15 A, max. 6.5 W |
| IR LED Range |
30m |
| Dimensions (W x D x H) |
Φ110.8 x 84.7 mm (Φ4.4? x 3.3?) |
| Weight |
Approx. 530 g (1.2 lb.) |
| Micro SD Slot |
Yes |
| Power Supply |
12 VDC ± 25%, reverse polarity protection PoE: 802.3af, Class 3 |
| Bracket 1 |
DS-1280ZJ-DM18 Junction Box |
| Bracket 2 |
DS-1250ZJ Rain Shade |
| Bracket 3 |
DS-1272ZJ-110 Wall Mount |
