| Sensor |
1/2.8" Progressive Scan CMOS |
| Max. Image Resolution |
1920 x 1080 |
| Minimum Illumination |
Color: 0.005 lux @(F1.2, AGC ON), 0 lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Lens |
2.8 mm, horizontal field of view: 108° 4 mm, horizontal field of view: 86.4° 6 mm, horizontal field of view: 52° 8 mm, horizontal field of view: 40° 12 mm, horizontal field of view: 25° |
| Adjustment Range |
Pan: 0°to 360°, tilt: 0°to 75°, rotate: 0°to 360° |
| Day& Night |
IR cut filter |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
3D DNR |
| Video Compression |
Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| Ultra Low Light Hikvision |
Yes |
| Video bit Rate |
32 Kbps to 16 Mbps |
| Ingress Protection IP |
IP67 |
| WDR |
120dB |
| Frame Rate |
50Hz: 25fps (1920 x 1080, 1280 x 960, 1280x720) 60Hz: 30fps (1920 x 1080, 1280 x 960, 1280x720) |
| Network Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| Local Storage |
SD Card |
| PoE Support |
Standard PoE |
| Working Temperature |
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
| Power Consumption |
6W |
| IR LED Range |
Up to 30 m |
| Dimensions (W x D x H) |
Φ 127.3 ? 95.9 mm (5.01? ? 3.78?) |
| Weight |
620 g |
| Micro SD Slot |
Yes |
| Bracket 1 |
DS-1273ZJ-130-TRL |
| Bracket 2 |
DS-1275ZJ |
| Bracket 3 |
DS-1276ZJ |
