| Sensor |
1/2.7" Progressive Scan CMOS |
| Max. Image Resolution |
1920 x 1080 |
| Minimum Illumination |
Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100, 000 s |
| Lens |
2.8mm |
| Adjustment Range |
Pan: 0° to 355°, tilt: 0° to 75° |
| Day& Night |
IR cut filter |
| Wide Dynamic Range |
Digital WDR |
| Digital Noise Reduction |
3D DNR |
| Video Compression |
Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG |
| Video bit Rate |
32 Kbps to 8 Mbps |
| Ingress Protection IP |
IP67 |
| WDR |
Digital WDR |
| Network Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
| Working Temperature |
30 °C to 60 °C (-22 °F to 140 °F) |
| Power Consumption |
12 VDC, 0.4 A, max. 5 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.15 A, max. 6.5 W |
| IR LED Range |
30m |
| Dimensions (W x D x H) |
Φ 110 mm x 82.4 mm (Φ 4.4" x 3.2") |
| Weight |
Approx. 410 g (0.9 lb.) |
| Power Supply |
12 VDC ± 25% PoE: 802.3af, Class 3 |
| Bracket 1 |
DS-1275ZJ-SUS Vertical Pole Mount |
| Bracket 2 |
DS-1280ZJ-DM18 Junction Box |
| Bracket 3 |
DS-1276ZJ-SUS Corner Mount |
