NeoGate TG200 - VoIP GSM Gateway(VoIP-GSM) - 2 GSM ports, 32SIP trunks
558.00€
744.00€
Description
NeoGate TG200 is a VoIP GSM gateway with 2 channels providing GSM network connectivity for softswitch and IP PBX. It supports two-way communication: VoIP to GSM and GSM to VoIP. Thus the calls costs could be significantly reduced by VoIP or GSM network.
Cost Savings - Save phone bills tremendously with mobile-to-mobile calls and LCR.
Back up - Work as a cost-effective backup when the landline network goes down.
Easy to install - Everything can be easily set up in the Web based management interface.
Easy to integrate - High compatibility with major IP PBX and softswitch brands.
| Specifications | |
| Number of Ports | 2 |
| GSM Frequency** | 850/900/1800/1900 MHz |
| WCDMA Frequency** | 850/1900 MHz, 850/2100 MHz, 900/2100 MHz |
| 4G Data | – |
| 4G LTE Band** | Depending on the module type. Check the supported band and operators. |
| Protocol | SIP, IAX2 |
| Antenna Splitter (4 in 1) | – |
| Transport | UDP, TCP, TLS, SRTP |
| Voice Codec | G.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, Speex |
| DTMF Mode | RFC2833, SIP Info, In-band |
| Echo Cancellation | ITU-T G.168 LEC |
| Calling Type | Termination (VoIP to GSM/WCDMA), Origination (GSM/WCDMA to VoIP) |
| Network Protocol | FTP, TFTP, HTTP, SSH |
| LAN | 1 10/100 Mbps Ethernet Interface |
| NAT Traversal | Static NAT, STUN |
| Network | DHCP, DDNS, Firewall, OpenVPN, Static IP, QoS, Static Route, VLAN |
| Operation Range | 0°C to 40°C, 32°F to 104°F |
| Power Supply | AC 100-240V |
| Storage Range | -20°C to 65°C, -4°F to 149°F |
| Dimensions (mm) | 213 x 160 x 44 |
| Humidity | 10-90% non-condensing |
